Koel iGreen Offerings
|
Features
|
|
| Low OPEX: | Best in class fuel efficiency with O2E technology |
| Robust and Reliable Product: | Lowest maintenance and trouble free product with Kirloskar Engines |
| Option of Air Cooled and Water Cooled Engines | |
| Compliance: | Latest Government Emission Norms CPCB II |
| Start Type: | Controller Based Easy Push Start Type |
| Customer Service: | Quick and affordable door step service coverage (420+ service touch points and 6000+ KOEL trained service professionals on field) |
| Warranty: | 2 years warranty & labour free onsite service under warranty period |
|
Prime Rating at rated rpm ( as per ISO8528)1 |
kVA | 40 | 40 | 45 | 62.5 | 62.5 | 82.5 | 100 | 125 | 125HD | ||||
| kW | 32 | 32 | 36 | 50 | 50 | 60 | 80 | 100 | 100 | |||||
|
Genset Model |
KG1-40AS | KG1-40WS | KG1-45WS | KG1-62.5AS | KG1-62.5AS | KG1-82.5WS | KG1-100WS | KG1-125WS | KG1-125WS HD | |||||
|
Frequency |
Hz | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | ||||
|
Power factor |
lagging | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | ||||
|
Voltage |
V | 230 (1Ø) & 415 (3Ø) | 415(3Ø) | |||||||||||
|
Governing class (As per ISO 8528 Part-V) |
G2 | G2 | G2 | G2 | G2 | G2 | G3 | G3 | G3 | |||||
|
Noise level |
dBA | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | < 75 | ||||
|
Fuel Consumption* |
At 100% Load | Ltrs/hr | 9.9 | 9.2 | 10.3 | 16.2 | 14.1 | 18.8 | 21.9 | 27.4 | 27.5 | |||
| At 75% Load | 7.9 | 7.4 | 8.7 | 12.7 | 11.3 | 13.8 | 16.9 | 20.2 | 21.4 | |||||
| At 50% Load | 5.8 | 5.5 | 5.9 | 8.9 | 7.5 | 9.9 | 12.2 | 15.3 | 15.3 | |||||
|
Fuel tank capacity |
Ltrs | 100 | 100 | 100 | 150 | 150 | 230 | 230 | 230 | 50 | ||||
|
Weight of genset with canopy (approx..)^ |
Dry | Kg | 1270 | 1250 | 1250 | 1700 | 1420 | 1710 | 2040 | 2090 | 2520 | |||
| Wet | Kg | 1370 | 1335 | 1335 | 1825 | 1550 | 1840 | 2240 | 2290 | 2730 | ||||
|
Overall dimensions of genset^ |
Length | mm | 2400 | 2550 | 2550 | 3150 | 2800 | 3200 | 3220 | 3220 | 3650 | |||
| Width | mm | 1050 | 1050 | 1050 | 1200 | 1100 | 1100 | 1300 | 1300 | 1350 | ||||
| Height | mm | 1670 | 1450 | 1450 | 1635 | 1595 | 1595 | 1795 | 1795 | 1915 | ||||
|
Electrical Battery starting voltage |
Volts-DC | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 | ||||
| ENGINE | ||||||||||||||
|
Engine Model |
HA494TCI G1 | 3R1040TA G1 | 3R1040TA G1 | HA694TCI G1 | 4R810TA G1 | 4R810TA G1 | 4K1080TA G2 | 4K1080TA G2 | 6R1080TA G1 | |||||
|
Rated output (Prime Continuous rating as per ISO 8528-1) |
KW | 41.19 | 41.2 | 41.2 | 61 | 61 | 74.8 | 114.7 | 114.7 | 114.7 | ||||
| HP | 56 | 56 | 56 | 83 | 83 | 102 | 156 | 156 | 175 | |||||
|
No. of cylinder |
Number | 4 | 3 | 3 | 6 | 4 | 4 | 4 | 4 | 6 | ||||
|
Cubic capacity |
Ltrs | 3.77 | 3.12 | 3.12 | 5.65 | 3.24 | 4.16 | 4.32 | 4.32 | 6.49 | ||||
|
Bore x Stroke |
mm | 100 x 120 | 105 x 120 | 105 x 120 | 105 x 120 | 100 x 120 | 96 x 112 | 105 x 120 | 105 x 125 | 105 x 125 | ||||
|
Rated Speed |
RPM | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 | ||||
|
Aspiration |
NA/TC/TA | TC | TA | TA | TC | TA | TA | TA | TA | TC | ||||
|
Lube Oil change period |
Hrs | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | 500 | ||||
|
Lube Oil Sump Capacity |
Ltrs | 8.3 | 8 | 8 | 11 | 10 | 10 | 14 | 14 | 18 | ||||
|
Coolant Capacity |
Ltrs | 11.5 | 11.5 | 117.5 | 24 | 21 | 21 | 28 | ||||||
|
ALTERNATOR |
||||||||||||||
|
Insulation Class |
Class H | |||||||||||||
|
Alternator Efficiency (at 100% load) 0.8 pf** |
% | 89.2 | 89.2 | 89.2 | 91 | 91 | 91.4 | 92 | 92.5 | 92.5 | ||||
|
Max Voltage Dip at Full Load 0.8 pf Lag |
Sec | < 20% | < 16% | < 16% | < 20% | < 20% | < 20% | < 20% | < 20% | < 20% | ||||
|
Max Time to build up rated voltage at Rated RPM |
< 5 sec provided engine reach the rated speed | < Voltage recovery time 6 sce | ||||||||||||
| For Intermediate ratings, Kindly contact nearest KOEL office | ||||||||||||||
